Maxiva™ UAXT with PowerSmart® Plus

High Efficiency Air­-Cooled UHF Multimedia TV Transmitter

Share this page on Facebook Share this page on Twitter Share this page on LinkedIn Share this page via email

Flexiva FAX 50 Compact Exciter Try Before You Buy Event - Click Here to Learn More Is Your Audio Stuck in the Mud? Clean It Up - Upgrade to HD Link with our trade-in program! Contact your sales representative to learn more! Contact your local sales representative today. Click here! Want to Know How to Accelerate Your ROI? Click Here!

Best of Show 2016: Maxiva High-Power UHF Air-Cooled Transmitters with High-Efficiency PowerSmart® Plus Technology Game Changer Award Finalist 2016: PowerSmart® Plus
OVERVIEW

The Maxiva™ UAXT, is a new technology, high-efficiency, air-cooled UHF solid-state transmitter. The state-of-the-art design combines GatesAir’s PowerSmart® Plus / PowerSmart® 3D architecture and Maxiva UAX Compact drive to provide today’s broadcaster unmatched efficiency, performance, reliability and quality. Designed with future broadcasting needs in mind, the Maxiva UAXT transmitter is a single transmitter platform capable of DVB-T/H, DVB-T2, ATSC, ATSC Mobile DTV, ISDB-Tb, CMMB, CTTB, and other digital standards.

For pre-filter average digital power levels up to 4kW OFDM and 7.2kW ATSC, the Maxiva UAXT transmitter is ideally suited for serving broadcasters needs for highly efficient, extremely compact and easy to maintain transmitter systems. The UAXT series utilizes GatesAir platform technologies derived from the Maxiva M2X multimedia exciter, PowerSmart 3D (or next-gen PowerSmart Plus) technology, new generation AC to DC power supplies and the latest 50 Volt LDMOS amplifier devices. This powerful technology blend provides best-in-class performance with respect to transmitter RF performance, efficiency, size, and upgradeability.

Maxiva UAXTE

The new, award-winning Maxiva UAXTE range of air-cooled UHF transmitters brings instant adaptability, enhanced flexibility, and seamless migration to future digital TV standards worldwide, including the emerging ATSC 3.0 modulation.

The high-efficiency architecture of the UAXTE is also based on the GatesAir PowerSmart® Plus architecture, and it directly integrates GatesAir’s latest high-performance modulator from the Maxiva XTE exciter into its architecture, giving broadcasters an out-of-the-box solution to simplify the input and output of multimedia services via a local- or wide-area IP network. The XTE modulator integration delivers a dramatic increase in digital signal processing capability, along with enhanced real-time adaptive correction.

The UAXTE design also breaks ground with an integrated, unified control system that eliminates the standard practice of a separate user interface for the exciter and transmitter. By centralizing control functionality into a single, modernized user interface, engineers can more easily control all settings and parameters.

Main Features of Maxiva™ UAXT with PowerSmart® Plus

  • High efficiency design incorporates GatesAir PowerSmart® Plus / PowerSmart® 3D technology, for best-in-class power efficiency and lowest TCO
  • Overall AC to RF efficiency up to 36% OFDM, 40% ATSC
  • Rugged, reliable design and construction
  • Digital average power levels up to 4 kW OFDM, 7.2 kW ATSC
  • Maxiva M2X exciter technology, allowing easy migration between different digital standards
  • Real-Time Adaptive Correction (RTAC™) technology is included with every system
  • Broadband high-efficiency power amplifier (PA) modules
  • Extremely compact design, allows multiple transmitters and N+1 configurations in a single rack
  • Hot-pluggable air-cooled high efficiency power supplies for simplified maintenance
  • Modular central control system for straightforward monitoring and in-depth diagnostics
  • Web-enabled remote graphical user interface (GUI)
  • Includes front panel LCD screen for display of transmitter parameters, including Forward Power and Reflected Power

Available Options

  • Integral GPS/GLONASS receiver for SFN timing
  • Dual exciters and switcher
  • Exciter external UPS
  • ASI/T2MI over IP (100/1000BASE-T)

Main Features of Maxiva™ UAXT with PowerSmart® Plus

  • High efficiency design incorporates GatesAir PowerSmart® Plus / PowerSmart® 3D technology, for best-in-class power efficiency and lowest TCO
  • Overall AC to RF efficiency up to 36% OFDM, 40% ATSC
  • Rugged, reliable design and construction
  • Digital average power levels up to 4 kW OFDM, 7.2 kW ATSC
  • Maxiva M2X exciter technology, allowing easy migration between different digital standards

More >

Product Literature

More >

More >

Image 1

Press and Accolades

Testimonials

"[GatesAir] made the task doable within the timelines we set to have the new [Maxiva UAXT HD transmitter] up and running."

Jim Meier, Chief Engineer, KTVH/KBGF/KMTF

"The Holy Grail in the transmitter business is a transistor power amplifier that is as (or more efficient) than a..."

Judge, Best of Show Award 2016, TV Technology

Awards

Articles

More >

Press and Accolades

Testimonials

I wanted to let you know that it has been an absolute pleasure working with GatesAir.  With all of the variables associated with a transmitter installation, you made the task doable within the time lines we set to have the new HD up and running.  Everyone from your customer service representative Therese Epping, your engineer David Hopson to Matthew Sanderford who installed the transmitter have been wonderful to interact with – all toward the common goal of installation and operation of the new KBGF GatesAir Maxiva UAXT HD transmitter.

Thank you for all you did for us!!!

Jim Meier, Chief Engineer, KTVH/KBGF/KMTF

The Holy Grail in the transmitter business is a transistor power amplifier that is as (or more efficient) than a tube amplifier. The Maxiva PowerSmart Plus transmitter architecture just got there.

Judge, Best of Show Award 2016, TV Technology
