Intraplex®IP链路
IP音频编解码器
概述
该Intraplex®IP链路系列IP音频编解码器提供了高端的功能以合理的价格。
提供的音频编码选项数组中，IP连接编解码器适用于工作室到变送器链接（补充交易）以及音频和分配网络。支持IP多播和多播流，使一个编码器喂多个解码器。
通过将可用于流和管理三个IP接口，所述IP链路系统可以提供的可靠性没有看到在同等价格的编解码器的电平。
作为最新加入的Intraplex系列音频传输产品，IP链路音频编解码器带来传说中的Intraplex可靠性的IP编解码器市场。
主要特点 Intraplex®IP链路
- IP链路100 / 100P：单双向立体声音频通道
- IP链路200：2个双向的立体声音频通道
- 标准：线性，AAC-LC，电视剧和G.722音频编码
- 可选：AAC-HE，AAC-HEv2，AAC-ELD，MPEG2，MPEG3和增强APTX音频编码
- 可选：自动音频响度均衡及计量符合EBU R-128和ITU-R
- 其他运输方式：透明AES高达192 kS / s的支持了AES复合FM多重信号
- 协议封装：RTP，Shoutcast一样/的Icecast，MPEG-TS
- 互操作标准的SIP / RTPenabled设备
- 冗余网络运行三个独立的IP接口
- 可选的冗余电源：+ 12V，-48V DC
- 内置沉默传感器拥有可选流开关
- 从USB驱动器或外部音源自动备份到音频播放
- Multicoding - 可以以多种格式的STL，备份和网络流编码相同的音频源
- 可选的动态数据流接合提供“无中断”运行和T1 / E1线路像较难预测的IP网络性能
- 优先流源的自动切换输出并切换回主，次流和备份源之间（数据流，USB，外部音源）
- 可编程RTP级前向纠错（FEC）方案
- 可编程时间分集，以打击突发丢包流和交错
- 集成了Intraplex IP链路调度自动化计划程序切换
- 集成了Intraplex LiveLook（网络分析和监控软件）
- N + 1 redudancy集成控制外部开关设备
- IP链路200 / 100P：SynchroCast™选项提供了动态管理的精确延时单频网（SFN）广播与联播
- 支持IP组播和multiunicast
- Web浏览器用户界面和SNMP网络管理
- 四多用途接线端子输入和输出提供
- 逻辑信号与timealignment到音频传送
- 流控制
- 报警通知
主要特点 Intraplex®IP链路
- IP链路100 / 100P：单双向立体声音频通道
- IP链路200：2个双向的立体声音频通道
- 标准：线性，AAC-LC，电视剧和G.722音频编码
- 可选：AAC-HE，AAC-HEv2，AAC-ELD，MPEG2，MPEG3和增强APTX音频编码
- 可选：自动音频响度均衡及计量符合EBU R-128和ITU-R
- 其他运输方式：透明AES高达192 kS / s的支持了AES复合FM多重信号
