Flexiva™ Compact

Air-Cooled FM Analog/Digital Transmitter / Exciter, Low Power - 50 W to 3.5 kW

Share this page on Facebook Share this page on Twitter Share this page on LinkedIn Share this page via email

Flexiva FAX 50 Compact Exciter Try Before You Buy Event - Click Here to Learn More Is Your Audio Stuck in the Mud? Clean It Up - Upgrade to HD Link with our trade-in program! Contact your sales representative to learn more! Contact your local sales representative today. Click here! Want to Know How to Accelerate Your ROI? Click Here!

OVERVIEW


The Flexiva™ Compact air-cooled FM solid-state transmitter family provides today’s broadcaster with a single transmission platform capable of analog and digital operation. Incorporating field-proven GatesAir technology, Flexiva transmitters deliver world-class performance, reliability and quality.

Flexiva is designed for low- and high-power requirements, up to 80 kW, while utilizing the most compact design on the market today. Flexiva continues the legacy of the highly successful line of GatesAir FM transmitters and combines innovative, new quadmode RF amplification and software-defined exciter technology to take FM transmission to the next level.

Featuring PowerSmart® technology, the Flexiva line offers unmatched efficiency that makes it ideal for all FM applications. The 50-volt LDMOS device technology delivers a dramatic increase in power density, lower operating costs and reduced cost of ownership over the life of the transmitter.

As the digital transmission leader, GatesAir has developed a solid core competency backed by years of experience in the complex technical areas that are essential for maximum transmitter performance.

Customers can count on GatesAir for implementation. The company offers a range of support options from standard 24/7 telephone technical assistance and parts to installation, training, full system design and field maintenance contracts.

Main Features of Flexiva™ Compact

  • Power levels up to 3850 W Analog FM, 3100 W FM+HD
  • Broadband, frequency agile design 87.5 to 108 MHz requires no tuning or adjustments
  • Best-in-class power efficiency for lowest operating costs
  • Compact, space-saving, 2, 3 or 4RU design
  • State-of-the-art, direct-to-carrier digital modulator
    • Integrated stereo encoder
    • ITU-R BS412 peak program/multiplex power limiter
    • Static RDS generator
    • 2 AES, 1 analog L/R and 2 composite program inputs with automatic failover switching
    • Digital MPX/Composite input over AES192 interface with fail-over switching
  • Operation over a wide range of voltage and power stability conditions
  • Operation at up to 1.5:1 VSWR with proportional foldback
  • Full remote control capability including:
    • Web-based HTML GUI interface
    • SNMP
    • Parallel control/monitoring
    • Extensive Fault, Warning and Operational parameter logging
  • N+1, dual transmitter and main/alternate; automatic switching capability
  • Optional Features
    • GPS receiver for SFN synchronization
    • Orban Optimod™ 5500H multi-band audio processor
    • Gen 4 HD Radio™ Exgine modulator card

Main Features of Flexiva™ Compact

  • Power levels up to 3850 W Analog FM, 3100 W FM+HD
  • Broadband, frequency agile design 87.5 to 108 MHz requires no tuning or adjustments
  • Best-in-class power efficiency for lowest operating costs
  • Compact, space-saving, 2, 3 or 4RU design
  • State-of-the-art, direct-to-carrier digital modulator
    • Integrated stereo encoder
    • ITU-R BS412 peak program/multiplex power limiter
    • Static RDS generator
